Micro Grinding Pulverizer

38500 INR/Unit

Get a Price/Quote

Product Details:

Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Micro Grinding Pulverizer Price And Quantity

Price 38500 INR/Unit
Minimum Order Quantity 1 Unit

Micro Grinding Pulverizer Trade Information

Supply Ability 100 Unit Per Month
Delivery Time 10 Days

Product Description

We provide Micro Grinding Pulverizers, which are high-speed hammer and screen mills that mechanically compress process material to reduce its size. This particular size reduction technique is distinguished by low heat buildup during milling, short residence times, and high energy.

Specification

MODEL NAME	1HP	2HP	3HP
MODEL NO.	AZ101	AZ201	AZ301
Grinding Capacity	10 to 12kg	15 to 17 kg	20 to 25 kg
Material	MS Body	MS Body	MS Body
Automation Grade	Semi Automatic	Semi Automatic	Semi Automatic
Power Source	Electric	Electric	Electric
Voltage (V)	220	220	220
Current (A)	6	10	15
Corrosion Resistance	Yes	Yes	Yes
Power Consumption	0.746KWH	1.5 KWH	2.30 KWH
Motor Speed	2880 rpm	2880 rpm	2880 rpm
Frequency (HZ)	50	50	50
Motor Type	Single Phase	Single Phase	Single Phase
Coating	Powder Coating	Powder Coating	Powder Coating
Chamber	Single Chamber	Single Chamber	Single Chamber
Machine Dimension Inch	L-24 W-13 H-32	L-26 W-14 H-35	L-31 W-15 H-41
Chamber Dimension Inch	6 Dia x 4 Depth	10 Dia x 5 Deapth	10 Dia x 6.5 Depth
