10 HP Masala Machine With Cyclone

10 HP Masala Machine With Cyclone About

The AATOMIZE AMC1002 is a 10HP high-capacity masala grinding machine with an integrated cyclone dust separator, purpose-built for dust-free, ultra-fine grinding of a wide range of spices including turmeric, chili, coriander, cumin, pepper, and herbal powders. This machine is designed for medium to large-scale commercial use, where hygiene, consistency, and production efficiency are essential.

Equipped with a double chamber structure, dual hopper, and high-speed dual beater mechanism, the AMC1002 ensures uniform grinding output, superior powder texture, and continuous dust-free operation. The cyclone system allows efficient powder collection and significantly reduces airborne particles.

Technical Specifications:

• Model: AMC1002

• Main Motor: 10HP (Three Phase 415V)

• Cyclone Motor: 1HP

• Beater Speed: 3840 RPM

• Grinding Capacity: 90120 kg/hr

• Output Type: Ultra-Fine Powder (Mesh Customizable)

• Construction: Powder-Coated Mild Steel

• Power Consumption: ~9.510.5 kWh

• Chamber Type: Double Chamber + Cyclone Separator

• Automation Grade: Semi-Automatic

• Warranty: 1 Year (Motor & Machine)

Ideal Applications:

• Herbal & Ayurvedic Powder Processing

• Retail Packaging & Private Label Brands

• FMCG Ingredient Supply Chains

• Contract Grinding Facilities

Why Choose AATOMIZE?

Ensures consistent grinding and low heat to preserve flavor and aroma in every batch.

Cyclone Dust-Free Operation

Heavy-Duty Industrial Build

Versatile Applications

High Efficiency, Low Power Usage

Low Maintenance, Easy Use

Made in India Trusted Worldwide

1-Year Warranty & Expert Support

Comprehensive support with quick-response service and easy spare part availability.
